Description

Technical Advantages

Performance and Features

  • Designed so that test results are in line with international standards DIN 12880.
  • PID temperature controller with LCD screen provides accurate and reliable temperature control.
  • Automatic calibration function, be able to adapt to a variety of laboratory environments.

Convenience

  • A product line breadth to meet a variety of needs
  • Wide range of options to meet a variety of experimental needs.
  • Temperature/Capacity/Liquid Flow/Pressure/Control Mode/Internal Circulation/External Circulation.
  • Convenient design for easy maintenance
  • Round curved inner angle is easy to clean.
  • Inner chamber is made from corrosion-resistant mirror stainless steel.

Safety

  • Preset On/Off function.
  • Built-in power interruption protection function, automatic run after power interruption.
  • Independent over-temperature protection meets DIN 12880 International standard requirements.
  • Temperature deviation alarm.
  • Over-current protection alarm.

Specifications

Capacity
Storage Tank (L): 8
Liquid (L): 5.2


Cooling Feature
Lowest Temp Without Load (°C): –20°C
Temperature Range (°C): –20°C to 20°C
Temperature Stability (°C): ±2°C
Cooling capacity(W)@20°C: 900
Cooling capacity(W)@10°C: 800
Cooling capacity(W)@0°C: 730
Cooling capacity(W)@–10°C: 570
Cooling capacity(W)@–20°C: 250
Refrigerant: R404A


Electrical
Whole unit power(W):  600
Power Requirement: AC 115V/60Hz

Pump
Pump type: DC Magnetic Drive Vortex
Recirculating Pump Power(W): 30
Pump Flow Rate(L/min): 6
Max. Pump Head(m):  9
Pump Max. Pressure (psi): 13 (90KPa)
Inlet/Outlet Tube OD(mm): Ø10 (DN15)

Other Features
Feet / Caster: Locking Casters
Noise (dB): =45
Dimensions
Liquid Tank (H x W x D) (mm): -
Exterior (H x W x D) (mm): -
Net Weight(kg): 41
Liquid tank Dimension(mm):  240 x 200 x 170
Exterior Dimension(mm)(Excluding casters): 315 x 455 x 624
Supported Rotavaps(Capacity x Units): 5L x 1
SKU Number: BRC15105U
